7024-46041-5230200 Murr Elektronik Cable Assemblies

Product Details

• Weight
  186 g
• Series
  Connector Systems
• Locking of ports
  Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
• Locking material
  Stainless steel 1.4404 (V4A)
• Cable weight [g/m]
  82,5 g
• Outer-Ø (jacket)
  7.9 mm ±5%
• Bend radius (fixed)
  5× outer Ø
• Travel speed (C-track)
  max. 3 m/s
• Operating current per contact
  max. 4 A
• Approval (cable)
  UL (AWM-Style 22126/11558), CE conform
• AWG
  similar to AWG 20 (0.5 mm²); similar to AWG 24 (0.25 mm²)
• Material (wire isolation)
  PP
• Torsion stress
  ±180°/m
• Rated surge voltage
  0.8 kV
• Compression gland
  M12 (SW14)
• Material (contact surface)
  Au
• Wire-Ø incl. isolation
  1.5 mm ±5% (0.5 mm²); 1.4 mm ±5% (0.25 mm²)
• Shield
  yes
• Bend radius (moving)
  10× outer Ø
• Operating voltage
  max. 30 V AC/DC
Temperature range
-40...+105 °C, depending on cable quality
Material (wire)
Cu wire, bare
Shield (Type)
Copper braid
Temperature range (mobile)
-25...+105 °C
Acceleration (C-track)
max. 10 m/s²
LED display
no
Material group
IEC 60664-1, category I
Material (contact)
Copper alloy
Resistor (core)
max. 39 Ω/km (0.5 mm²), max. 78 Ω/km (0.25 mm²); (20 °C)
Color (jacket)
pastel blue
Form
46041
Material
PP
Material (gasket)
EPDM
Single wire Ø (core)
0.15 mm (0.5 mm²); 0.1 mm (0.25 mm²)
optical shield cover
min. 80%
Temperature range (fixed)
-40...+105 °C
Product article number of manufacturer
7024-46041-5230200
No. of poles
6
Standards
DIN EN 61076-2-101 (M12), FDA conform
Color/numbering of wires
(bl, wh, br, bk) + (gr, pk)
Test voltage
3000 V
No. of torsion cycles
max. 2 Mio. (25 °C)
Coding
A-coded
Mounting method
inserted, tightened
Material (contact carrier)
PP, ice blue
Construction (core)
28× 0.15 mm (0.5 mm²); 32× 0.1 mm (0.25 mm²); (multi-strand wire class 6)
Nominal voltage
300 V AC
Cable length
2 m
suitable for corrugated tube (internal Ø)
without
Cable identification
523
Diameter (core)
4× 0.5 + 2× 0.25 mm²
Jacket Color
gray
Protection
IP65, IP68, IP69K inserted and tightened (EN 60529)
Pollution Degree
3
Material (jacket)
TPE-S
No. of bending cycles (C-track)
max. 4 Mio. (25 °C)
