7005-40881-6360300 Murr Elektronik Cable Assemblies

Product Details

• Weight
  204 g
• Series
  Connector Systems
• Form
  40881
• suitable for corrugated tube (internal Ø)
  10 mm
• Cable weight [g/m]
  56,1 g
• Wire-Ø incl. isolation
  1.85 mm ±5%
• thermal resistance
  flame retardand UL 1581 Section 1090 (H), CSA FT2 / IEC 60332-2-2
• No. of bending cycles (C-track)
  max. 10 Mio. (25 °C)
• Current consumption
  max. 15 mA
• Locking material
  PA
• Cable Type
  3 (PUR)
• Material (wire isolation)
  PP
• Outer-Ø (jacket)
  5.9 mm ±5%
• Operating current per contact
  max. 4 A
• Pollution Degree
  3
• AWG
  similar to AWG 18
• Color/numbering of wires
  bk numbered, gnye longitudinally striped
• Test voltage
  2500 V AC
• Product article number of manufacturer
  7005-40881-6360300
• LED display
  yellow
Housing
Black plastic (gray on request)
Resistor (core)
max. 26 Ω/km (20 °C)
Shield
no
Stranding combination
3 wires twisted
Bend radius (fixed)
5× outer Ø
Torsion speed
35 cycles/min
Rated surge voltage
0.8 kV
Switch off delay time
max. 20 ms
Material (wire)
Cu wire, bare
Material (jacket)
PUR
Color (jacket)
black
Bend radius (moving)
10× outer Ø
Operating voltage
24 V AC ±20% / DC ±25%
Material (gasket)
Silicon
Single wire Ø (core)
0.15 mm
Material property (jacket)
CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant
Temperature range (mobile)
-25...+80 °C, (+90 °C at max. 10 000 operating hours)
Cable length
3 m
Locking of ports
M3/M12×1 mm (recommended torque 0.4/0.6 Nm)
Compression gland
M12 (SW13)
Approval (cable)
cURus (AWM-Style 20549/10493); CE conform
Material property (wire isolation)
CFC-, halogen-, cadmium-, silicone- and lead-free
Temperature range (fixed)
-40...+80 °C, (+90 °C at max. 10 000 operating hours)
No. of torsion cycles
max. 2 Mio. (25 °C)
Switch off peak
max. 55 V
Protection
IP67 inserted and tightened (EN 60529)
Construction (core)
42× 0.15 mm (multi-strand wire class 6)
Shore hardness (jacket)
90 ±5 A
Current load capacity
to DIN VDE 0298-4
Torsion stress
±180°/m
Material group
IEC 60664-1, category I
Temperature range
-25...+85 °C, depending on cable quality
Diameter (core)
3× 0.75 mm²
chemical resistance
good resistance to oil, gasoline and chemicals (EN 60811-404)
Travel speed (C-track)
max. 3 m/s
Material
PBT/PUR
Cable identification
636
Shore hardness (wire isolation)
70 ±5 D
Nominal voltage
300 V AC
Acceleration (C-track)
max. 10 m/s²
