7005-12041-6150030 Murr Elektronik Cable Assemblies

Product Details

• Weight
  26 g
• Series
  Connector Systems
• Operating current per contact
  max. 4 A
• Mounting method
  inserted, tightened
• Construction (core)
  19× 0.15 mm (multi-strand wire class 5)
• Material (jacket)
  PVC
• Material property (jacket)
  CFC-, cadmium-, silicone- and lead-free
• Material group
  IEC 60664-1, category I
• Locking material
  Polyamide
• Approval (cable)
  UL (AWM-Style 2464/1731), CSA
• Material (wire isolation)
  PVC
• Jacket Color
  black
• Temperature range (fixed)
  -30...+80 °C
• Compression gland
  M12 (SW13)
• Outer Ø
  5.2 mm ±5%
• Single wire Ø (core)
  0.15 mm
• Color/numbering of wires
  br, bk, bl, wh, gnye longitudinally striped
• thermal resistance
  flame retardant UL 1581 VW1 / CSA FT1
• Cable length
  0,3 m
• Locking of ports
  Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
Protection
IP67 inserted and tightened (EN 60529)
Resistor (core)
max. 60 Ω/km (20 °C)
Shore hardness (jacket)
85 ±5 A
Bend radius (fixed)
5× outer Ø
Coding
A-coded
Material (contact surface)
Au
Cable weight [g/m]
48,4 g
Stranding combination
5 wires twisted around central filler
chemical resistance
good resistance to oil, gasoline and chemicals
Temperature range (mobile)
-5...+80 °C
Operating voltage
max. 125 V AC/DC
suitable for corrugated tube (internal Ø)
without
No./diameter of wires
5× 0.34 mm²
Cable Type
1 (PVC)
Material property (wire isolation)
CFC-, cadmium-, silicone- and lead-free
Color (jacket)
black
Bend radius (moving)
10× outer Ø
LED display
no
Wire isolation
PVC (br, wh, bl, bk, gnye)
Material (wire)
Cu wire, bare
Diameter (core)
5× 0.34 mm²
Test voltage
2000 V AC
Rated surge voltage
1.5 kV
Pollution Degree
3
Stripping length (jacket)
20 mm
Wire-Ø incl. isolation
1.25 mm ±5%
Current load capacity
to DIN VDE 0298-4
Form
12041
Material (contact)
Copper alloy
AWG
similar to AWG 22
Shield
no
Nominal voltage
UL 300 V AC
No. of poles
5
Standards
DIN EN 61076-2-101 (M12)
Cable identification
615
Shore hardness (wire isolation)
45 ±5 D
Outer-Ø (jacket)
5.2 mm ±5%
Product article number of manufacturer
7005-12041-6150030
