7002-12691-0000000 Murr Elektronik Cable Assemblies
Part#:7002-12691-0000000
Manufacturer:Murr Elektronik
Category:Cable Assemblies
Product Lifecycle:Active
Product description
7002-12691-0000000 Murrelektronik - MOSA M12 FEMALE 90° 3LED (IDC) V2A, 4-pol. 0.25...0.5mm²
Product Details
- Weight 24 g
- Series Connector Systems
- Locking material Stainless steel 1.4305 (V2A)
- Locking of ports Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
- Sealing range (cable Ø) 4...5.1 mm
- Form 12691
- Operating current per contact max. 4 A
- Connection cross section 0.25...0.5 mm² (conductor diameter min. 0.1 mm)
- Outer wire Ø 1.2...1.6 mm
- Operating voltage 24 V AC/DC ±25%
- Product article number of manufacturer 7002-12691-0000000
- Protection IP67 inserted and tightened (EN 60529)
- Temperature range -25...+85 °C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 7002-12691-0000000 on Applied Automation is $42.80. Order now.
