7000-C0101-0180000 Murr Elektronik Cable Assemblies

Product Details

• Weight
  8805 g
• Series
  Connector Systems
• Resistor (core)
  max. 26 Ω/km (20 °C)
• Approval (cable)
  CE conform
• Color/numbering of wires
  bk numbered, gnye longitudinally striped
• Wire-Ø incl. isolation
  1.8 mm ±5%
• Outer-Ø (jacket)
  7.0 mm ±5%
• Color (jacket)
  yellow
• Wire isolation
  PVC (bk num, gnye)
• Single wire Ø (core)
  0.2 mm
• Shore hardness (jacket)
  80 ±5 A
• Bend radius (moving)
  10× outer Ø
• No./diameter of wires
  5× 0.75 mm²
• Material (jacket)
  PVC
• Shield
  no
• Temperature range (mobile)
  -5...+70 °C
• Product article number of manufacturer
  7000-C0101-0180000
• Material (wire)
  Cu wire, bare
• Material property (wire isolation)
  CFC-, cadmium-, silicone- and lead-free
• chemical resistance
  good resistance to oil, gasoline and chemicals
Test voltage
3000 V AC
Current load capacity
to DIN VDE 0298-4
Outer Ø
7.0 mm ±5%
Shore hardness (wire isolation)
43 ±5 D
Jacket Color
yellow
Bend radius (fixed)
5× outer Ø
Cable weight [g/m]
94,6 g
AWG
similar to AWG 18
Material property (jacket)
CFC-, cadmium-, silicone- and lead-free
Temperature range (fixed)
-30...+70 °C
Construction (core)
24× 0.2 mm (multi-strand wire class 5)
Stranding combination
5 wires twisted around central filler
Nominal voltage
300/500 V AC
Cable Type
1 (PVC)
Cable identification
018
Material (wire isolation)
PVC
Diameter (core)
to DIN VDE 0298-4
