7000-88421-2330060 Murr Elektronik Cable Assemblies

7000-88421-2330060 on Applied Automation
Murr Elektronik

Part#:7000-88421-2330060

Manufacturer:Murr Elektronik

Category:Cable Assemblies

Product Lifecycle:Active

Product description

7000-88421-2330060 Murrelektronik - M8 MALE 0° /MSUD VALVE PLUG FORM C 8 MM(SMALL), PUR 3X0.34 GRAY, UL/CSA, drag ch 0.6m

Product Details

  • Weight
    40 g
  • Series
    Connector Systems
  • Locking of ports
    M3/M8 (recommended torque 0.4 Nm)
  • LED display
    LED (yellow)
  • Single wire Ø (core)
    0.1 mm
  • Shield
    no
  • Torsion stress
    ±180°/m
  • Operating voltage
    24 V AC ±20% / DC ±25%
  • Additional suppressor
    Diode/Z-Diode
  • Cable weight [g/m]
    29,7 g
  • Diameter (core)
    3× 0.34 mm²
  • Material property (jacket)
    CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant
  • Current load capacity
    to DIN VDE 0298-4
  • Protection
    IP65, IP66K, IP67, IP68 inserted and tightened (EN 60529)
  • Compression gland
    M8 (SW9)
  • Material (wire isolation)
    PP
  • Material (jacket)
    PUR
  • Bend radius (moving)
    10× outer Ø
  • Cable length
    0,6 m
  • Form
    88421
  • Temperature range
    -25...+85 °C, depending on cable quality
  • AWG
    similar to AWG 22
  • thermal resistance
    flame retardand UL 1581 Section 1090 (H), CSA FT2 / IEC 60332-2-2
  • Temperature range (mobile)
    -25...+80 °C, (+90 °C at max. 10 000 operating hours)
  • Locking material
    Zinc die casting, matte nickel plated
  • Cable identification
    233
  • Wire-Ø incl. isolation
    1.25 mm ±5%
  • Shore hardness (jacket)
    90 ±5 A
  • Temperature range (fixed)
    -40...+80 °C, (+90 °C at max. 10 000 operating hours)
  • Product article number of manufacturer
    7000-88421-2330060
  • Rated surge voltage
    0.8 kV
  • Approval (cable)
    cURus (AWM-Style 20549/10493); CE conform
  • Color/numbering of wires
    br, bk, bl
  • Nominal voltage
    300 V AC
  • Travel speed (C-track)
    max. 3 m/s
  • Material group
    IEC 60664-1, category I
  • Switch off delay time
    max. 20 ms
  • Resistor (core)
    max. 57 Ω/km (20 °C)
  • Shore hardness (wire isolation)
    70 ±5 D
  • Outer-Ø (jacket)
    4.1 mm ±5%
  • Bend radius (fixed)
    5× outer Ø
  • Torsion speed
    35 cycles/min
  • Operating current per contact
    max. 4 A
  • Pollution Degree
    3
  • Construction (core)
    42× 0.1 mm (multi-strand wire class 6)
  • Test voltage
    2500 V AC
  • No. of torsion cycles
    max. 2 Mio. (25 °C)
  • Switch off peak
    max. 55 V
  • Housing
    Black plastic (gray on request)
  • Cable Type
    3 (PUR)
  • Material property (wire isolation)
    CFC-, halogen-, cadmium-, silicone- and lead-free
  • Color (jacket)
    gray
  • No. of bending cycles (C-track)
    max. 10 Mio. (25 °C)
  • Material
    MSUD (PBT); M8 (PUR)
  • Material (wire)
    Cu wire, bare
  • Stranding combination
    3 wires twisted
  • chemical resistance
    good resistance to oil, gasoline and chemicals (EN 60811-404)
  • Acceleration (C-track)
    max. 10 m/s²

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 7000-88421-2330060 on Applied Automation is $39.60. Order now.
