6652110 Murr Elektronik Control Circuits
Part#:6652110
Alt. Part#:52110
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
6652110 Murrelektronik - MIRO 12.4 24VDC-2U INPUT RELAY, IN: 24 VDC - OUT: 250 VAC/DC / 6 A, 2 C/O contact - 6,2 mm spring clamp
Product Details
- Weight 60 g
- Series Interface Modules
- Test isolation voltage 4 kV; safe separation (EN 60947-1)
- Connection voltage - current 24 V DC (19.2...30 V DC) - 18 mA
- LED display LED (green)
- Contact material Ag Sn O2 hv
- Switching current per output (Signal) max. 20 mA
- Min. load current 1 mA (12 V DC)
- Switching current per output max. 6 A
- Mech./ elect. life 20 000 000 switching cycles/load dependent
- Switching voltage max. 250 V AC/DC
- Power rating (voltage dependent) max. 1500 VA/120 W
- AC-15 3 A (24/110/230 V AC)
- Temperature range -25...+60 °C
- AC-12 6 A (24/110/230 V AC)
- Energize/release/contact bounce time 10/15/1.5 ms
- Product article number of manufacturer 6652110
- Dimensions H×W×D 90×12.4×65 mm
- DC-13 1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)
- Mounting method DIN-rail mountable (EN 60715)
- Switching frequency max. 10 Hz
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 6652110 on Applied Automation is $67.25. Order now.
