6652130 Murr Elektronik Control Circuits
Part#:6652130
Alt. Part#:52130
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
6652130 Murrelektronik - MIRO 12.4 110V-2U-FK OUTPUT RELAY, IN: 110 VACDC - OUT: 250 VAC/DC / 6 A, 2 C/O contact - 12,4 mm spring clamp
Product Details
- Weight 46 g
- Series Interface Modules
- Test isolation voltage 4 kV; safe separation (EN 60947-1)
- Switching voltage max. 250 V AC/DC
- Switching frequency max. 10 Hz
- Mounting method DIN-rail mountable (EN 60715)
- AC-12 6 A (24/110/230 V AC)
- Dimensions H×W×D 90×12.4×65 mm
- Power rating (voltage dependent) max. 1500 VA/120 W
- Switching current per output max. 6 A
- DC-13 1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)
- Contact material Ag Sn O2
- LED display LED (green)
- Temperature range -20...+50 °C
- AC-15 3 A (24/110/230 V AC)
- Energize/release/contact bounce time 10/15/1.5 ms
- Connection voltage - current 110 V AC/DC (95...121 V AC/DC) - 7 mA
- Mech./ elect. life 20 000 000 switching cycles/load dependent
- Product article number of manufacturer 6652130
- Min. load current 100 mA (12 V DC)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 6652130 on Applied Automation is $79.90. Order now.
