52560 Murr Elektronik Control Circuits
Part#:52560
Alt. Part#:52550
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
52560 Murrelektronik - MIRO TH 24VDC SK 5P OPTO-COUPLER MODULE, IN: 53 VDC - OUT: 250 VAC / 0,5A, 6,2 mm screw-type terminal
Product Details
- Weight 27 g
- Series Interface Modules
- Housing Black plastic, flame retardant
- Switching frequency max. 20 Hz, depending on suppression
- LED display LED (yellow)
- Temperature range -20...+60 °C
- Switching current per output 1 mA...0.5 A
- Control current 6 mA
- Test isolation voltage 2.5 kV
- Switching voltage 12...250 V AC
- Leakage current (output is open) max. 0.3 mA
- Voltage range ON 10...44 V DC
- Dimensions H×W×D 91×6.2×71 mm
- Switching time ON/OFF 10/10 ms
- Voltage range OFF 0...3 V DC
- Saturation voltage (across output) max. 1.5 V AC
- Product article number of manufacturer 52560
- Mounting method DIN-rail mountable (EN 60715)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 52560 on Applied Automation is $69.85. Order now.
