50015 Murr Elektronik Control Circuits
Part#:50015
Alt. Part#:50043
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
50015 Murrelektronik - AMS 4-10/44-2 OPTO-COUPLER MODULE, In: 24 VDC - Out: 24 VDC / 2A, 22.5 mm, spring clamp
Product Details
- Weight 55 g
- Series Interface Modules
- LED display LED (yellow)
- Temperature range -25...+50 °C
- Mounting method DIN-rail mountable TH35 or G32 (EN 60715)
- Input current 27 mA
- Switching time ON/OFF 1/5 ms
- Test isolation voltage 2.5 kV
- Voltage range OFF 0...6 V DC
- Housing Black plastic, flame retardant
- Leakage current (output is open) max. 0.01 mA
- Switching frequency max. 10/1 Hz (resist./ind.)
- Switching voltage 5...30 V DC
- Voltage range ON 20...30 V DC
- Switching current per output 1 mA...2 A
- Product article number of manufacturer 50015
- Saturation voltage (across output) max. 0.05 V DC
- Dimensions H×W×D 75×22.5×102 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 50015 on Applied Automation is $152.20. Order now.
