NPV2-1C-23-12 Clippard Pneumatic Components
Part#:NPV2-1C-23-12
Manufacturer:Clippard
Category:Pneumatic Components
Product Lifecycle:Active
Product description
2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC, Max. Pressure: 14 psi
Product Details
- Function 2-Way Normally-Closed
- Voltage 12 VDC
- Medium Air, Water, Gas & Fluids
- Response Time 5 to 25 ms
- Max PSI 14 psi
- Tubing, Length Comes with 12" of selected tubing. Additional tubing available separately.
- Pressure Range 20 to 30 psig with standard medical/lab grade silicone tubing
- Tubing, Tear Strength 200 ppi
- Connector 18" Wire Leads
- Tubing, Elongation at Break 770%
- Mount #4-40. M3 also available.
- Tubing, Tensile Strength at Break 1,450 psi
- Connection 18" Wire Leads
- Weight 0.2000
- Power Consumption 1.5 Watts
- Tubing, Wall Thickness 0.0313"
- Materials, Wetted Sanitary Food Grade Platinum-Cured Silicone
- Tubing, Durometer Hardness 50 Shore A
- Tubing Size 1/16" ID-1/8" OD, Food Grade
- Tubing, Modulus at 200% 280 psi
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of NPV2-1C-23-12 on Applied Automation is $91.52. Order now.
