MTV-2 Clippard Electronic Components

MTV-2 on Applied Automation
Clippard

Part#:MTV-2

Manufacturer:Clippard

Category:Electronic Components

Product Lifecycle:Active

Product description

2-Way Toggle Valve, NP Brass Toggle, #10-32

Product Details

  • Max PSI
    300 psig
  • Mount
    #15/32-32 Thread
  • Material, Spring
    Stainless Steel Stem & Spring
  • Function
    2-Way Normally-Closed
  • Port, Inlet / Port, Outlet
    #10-32 / #10-32
  • Input PSI
    150 psig max.
  • Operating Temperature Range
    32 to 230°F
  • Air Flow
    113 l/min @ 50 psig; 190 l/min @ 100 psig
  • Material, Toggle
    Nickel-Plated Steel
  • Included Item(s)
    Nut & Lockwashers
  • Unit
    Imperial
  • Medium
    Air, Water or Oil
  • Material, Seals
    Nitrile Std. FKM or Krytox optional.
  • Material, Body
    Brass
  • Weight
    0.1700

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of MTV-2 on Applied Automation is $25.85. Order now.
