AM1648HP30 Allied Moulded Products Pushbutton Enclosures

Product Details

• UL Standard
  508A
• UL CCN
  NITW
• UL File No.
  E120175
• Width
  14.4 in
• Height
  16.27 in
• Depth
  8 in
• NEMA Rating
  4X
• Material
  Fiberglass
• Color
  Gray
• Type
  Wallmount
• Door Qty
  1
• Volume:
  1905 cu. in.
• Width:
  14.4 in
• UPC:
  85339916598
• Mounting Description:
  Stainless steel feet fastened to back side brass inserts
• Closure Type:
  2-Screw
• Application:
  Designed to protect push-button switches from damage and wear, these enclosures have holes for mounting push buttons and an internal compartment to house associated wires and mechanisms. Push buttons are often used for operating industrial machines or pro
• Usable Depth:
  7.68 in
• Carton Quantity:
  1
• Depth:
  8 in
Cover Type:
Opaque
Height:
16.27 in
Carton Weight:
14 lbs
Brand:
AM Series
Enclosure Type:
Pushbutton
Standards:
UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
UNSPSC:
39121326
Country of Origin:
United States of America
Color:
Gray (RAL 7035)
Material:
ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
Additional Materials:
316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
Features:
Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
