7000-17161-9730020 Murr Elektronik Cable Assemblies
Part#:7000-17161-9730020
Manufacturer:Murr Elektronik
Category:Cable Assemblies
Product Lifecycle:Active
Sep 6, 2026
Product description
7000-17161-9730020 Murrelektronik - M12 MALE FLANGE PLUG A CODED FRONT MOUNT, PP-wires 8x0,25 0.2m
Product Details
- Weight 20 g
- Series Connector Systems
- Locking of ports Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
- Temperature range (mobile) -25...+90 °C
- Temperature range -25...+85 °C
- Pollution Degree 3
- Outer Ø 1.25 mm ±5%
- No./diameter of wires 8× 0.25 mm²
- Operating current per contact max. 2 A
- Temperature range (fixed) -40...+90 °C
- Operating voltage max. 30 V AC/DC
- Cable number 973
- Protection IP67 inserted and tightened (EN 60529)
- Protection NEMA 3, 4, 6P (UL 50E)
- Material group IEC 60664-1, category I
- Bend radius (fixed) 10× outer Ø
- Rated surge voltage 0.8 kV
- Product article number of manufacturer 7000-17161-9730020
- Form 17161
- Wire isolation PUR (wh, br, gn, ye, gr, pk, bl, rd)
- Cable length 0,2 m
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 7000-17161-9730020 on Applied Automation is $40.05. Order now.
7000-17161-9730020 Related Documents
Similar products from: Murr Elektronik Cable Assemblies
This item can ship within 1 day!
Manufacturer warranty
7000-17161-9730020 Murr Elektronik
$40.05
Your price can be lower.
Log in or Create account to check your discount
Stock:
Select Qty:
$40.05
$40.05 each
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 7000-17161-9730020 with other Cable Assemblies products
Weight
Series
Locking of ports
Temperature range (mobile...
Temperature range
Pollution Degree
Outer Ø
No./diameter of wires
Operating current per con...
Temperature range (fixed)
Selected product
7000-17161-9730020
Murr Elektronik
7000-17161-9730020 Murrelektronik - M12 MALE FLANGE PLUG A CODED FRONT MOUNT, PP-wires 8x0,25 0.2m
Weight20 g
SeriesConnector Systems
Locking of portsScrew thread (M12×1 mm) reco...
Temperature range (mobile)-25...+90 °C
Temperature range-25...+85 °C
Pollution Degree3
Outer Ø1.25 mm ±5%
No./diameter of wires8× 0.25 mm²
Operating current per contactmax. 2 A
Temperature range (fixed)-40...+90 °C
7000-17181-9730200
Murr Elektronik
7000-17181-9730200 Murrelektronik - M12 female receptacle A-cod. front mount, wires PP 8x0.25 2m
Weight84 g
SeriesConnector Systems
Locking of portsScrew thread (M12×1 mm) reco...
Temperature range (mobile)-
Temperature range-25...+85 °C
Pollution Degree-
Outer Ø-
No./diameter of wires8× 0.25 mm²
Operating current per contactmax. 2 A
Temperature range (fixed)-
7000-48111-0000000
Murr Elektronik
7000-48111-0000000 Murrelektronik - M12-PANEL FEED THROUGH 8POLE A CODED
Weight27 g
SeriesConnector Systems
Locking of portsScrew thread (M12×1 mm) reco...
Temperature range (mobile)-
Temperature range-25...+85 °C
Pollution Degree3
Outer Ø-
No./diameter of wires-
Operating current per contactmax. 2 A
Temperature range (fixed)-
About the manufacturer
Applied Automation is an authorized Murr Elektronik distributor, offering a robust selection of high-quality components engineered to drive efficiency and innovation in industrial applications. Murr Elektronik, a leader in the electronics industry, specializes in providing sophisticated automation solutions that cater to diverse sectors by integrating cutting-edge technology with unmatched enginee...
Recently viewed products
Relevant products
FAQ
What is the price of 7000-17161-9730020?
Purchase the 7000-17161-9730020 from Applied Automation at the price of $40.05. Order today.
10 in stock
7000-17161-9730020 Murrelektronik - M12 MALE FLANGE PLUG A CODED FRONT MOUNT, PP-wires 8x0,25 0.2m
