761.000.55 Werma Buzzers

Product Details

• Protection category
  IP65
• Connection
  Spring-type terminal
• Working temperature minimum
  -40°C
• Working temperature maximum
  +50°C
• Protection class
  Protection class 2
• Volume (max) at 1m distance
  105,0 dB (A)
• Conforms with CE
  Yes
• ATEX-guidance
  2014/34/EU
• Conform with ATEX-directive
  Yes
• ICAO Certification
  No
• Cable entry
  Screwed cable gland
• Length
  104 mm
• Cable entry minimum
  d = 7 mm
• Operating voltage
  24V
• Housing colour
  Black
• Width
  178 mm
• Height
  232 mm
• Type of fixing
  Wall mounting
• Weight with packaging
  1505 g
• Pollution degree
  3
Operating voltage type
DC
Acoustic service life
250 h minimum
cross-sectional area maximum
2,50mm² / 14AWG
Materials
PC
Cable entry maximum
d = 11 mm
Tension relief
Present (conforms to VDE)
Rated operational voltage
24 VDC
Operating voltage tolerance
+/- 10%
Audio frequency
145 Hz
WEEE
Yes
Ex label for dust
II2D Ex tb IIIC T70°C Db
Conforms with FCC
No
Conforms with GL
No
Conforms with AS-I
No
Rated inrush current
3.000 mA
Rated operational current
350 mA
Acoustic signal image
Continuous tone
Conforms with IC
No
Conforms with RoHS CN
No
Product weight
1391 g
Ex approval number
BVS 03 ATEX E 118 X
Conforms with CCC
No
Ex label for gas
II2G Ex eb mb IIC T5 Gb
Safety information
Observe instruction-leaflet!
Conforms with VdS
No
