718.000.55 Werma Buzzers

Product Details

• Working temperature maximum
  +50°C
• Product weight
  41 g
• Acoustic signal image
  Continuous tone
• ATEX-guidance
  2014/34/EU
• Conforms with IC
  No
• Conforms with VdS
  No
• Materials
  PC/ABS
• Operating voltage
  24V
• WEEE
  Yes
• Safety information
  2020012310348919
• ICAO Certification
  No
• Connection
  Flat plug
• Weight with packaging
  59 g
• Pollution degree
  2
• Conforms with IECEx
  EN IEC 60079-0:2018
• Conforms with UL
  Yes
• Type of fixing
  Built-in mounting
• Rated operational current
  20 mA
• Conforms with CE
  Yes
• Ex approval number
  DMT 98 ATEX E005 X
Conforms with FCC
No
Working temperature minimum
0°C
Operating voltage tolerance
+/- 10%
Acoustic service life
5,000 h minimum
Ex label for gas
II2G Ex ib IIC T4/T5/T6 Gb
Conforms with CCC
Observe instruction-leaflet!
Housing colour
Grey
Rated inrush current
50 mA
Conform with ATEX-directive
Yes
Conforms with CCC-Ex
No
Conforms with GL
No
Height
48 mm
Protection class
Protection class 3
Conforms with RED directive
No
CCC-Ex approval number
Yes
Conforms with RoHS CN
No
Diameter
43 mm
Operating voltage type
DC
Audio frequency
2400 Hz
Ex-standard
EN 60079-11:2012
EAC certificate available
No
Protection category
IP30
Rated operational voltage
24 VDC
Volume (max) at 1m distance
90,0 dB (A)
Ex label for dust
-
Conforms with AS-I
No
