573.000.55 Werma Buzzers

Product Details

• Cable entry
  Screwed cable gland
• Housing colour
  Black
• Operating voltage type
  DC
• Protection class
  Protection class 1
• Conforms with UL
  No
• Conforms with GL
  No
• Width
  104 mm
• Cable entry maximum
  d = 10 mm
• Type of fixing
  Wall mounting
• Rated operational voltage
  24 VDC
• Acoustic service life
  250 h minimum
• Conforms with IC
  No
• Conforms with VdS
  No
• Materials
  PC/ABS
• Height
  232 mm
• Product weight
  1200 g
• Acoustic signal image
  Continuous tone
• Conforms with CE
  Yes
• EAC certificate available
  Yes
• Length
  232 mm
Tension relief
Present (conforms to VDE)
Operating voltage tolerance
+/- 10%
Volume (max) at 1m distance
105,0 dB (A)
Conforms with CCC
No
cross-sectional area maximum
2,50mm² / 14AWG
Working temperature minimum
-30°C
Working temperature maximum
+50°C
Rated operational current
350 mA
Conforms with FCC
No
Conforms with RoHS CN
No
Protection category
IP65
Operating voltage
24V
Pollution degree
3
WEEE
Yes
Conforms with AS-I
No
Connection
Screw terminals
Cable entry minimum
d = 5 mm
Weight with packaging
1300 g
Rated inrush current
<5A
Conform with ATEX-directive
No
ICAO Certification
No

573.000.55 Related Documents
