25015EP3OFP449TS-W22 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  380 V
• Output Rating
  250 HP
• Rated Speed
  1475 rpm
• Flange Type
  Without
• Output
  250 HP (185 kW)
• Moment of inertia (J)
  112 sq.ft.lb
• Rotation¹
  Both (CW and CCW)
• L. R. Amperes
  1865 A
• Service factor
  1.15
• Altitude
  1000 m.a.s.l.
• Number of poles
  4
• Frequency
  50 Hz
• Design
  B
• Mounting
  F-1
• Flange
  Without
• Rated current
  339 A
• Locked rotor torque
  180 %
• Enclosure
  IC411 - TEFC
• Terminal box¹
  Left position
Frame
447/9TS
Rated voltage
380 V
Starting Method
Direct On Line
Standard
NEMA MG-1
Rated speed
1475 rpm
Rated torque
890 ft.lb
Duty Cycle
Cont.(S1)
Noise level²
69.0 dB(A)
LRC
5.5x(Code E)
Insulation Class
F
Approx. weight³
2800 lb
No load current
91.0 A
Temperature rise
80 K
Voltage
380-415 V
Number of Poles
4
Breakdown torque
210 %
Degree of Protection
IP55
Output rating
250 HP
Slip
1.67 %
Locked rotor time
46s (cold) 26s (hot)
Ambient temperature
-20°C to +40°C
Synchronous speed
1500 rpm
