20009ST3QIE449T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 460 V
- Output Rating 200 HP
- Rated Speed 891 rpm
- Flange Type Without
- L. R. Amperes 1476 A
- Locked rotor time 45s (cold) 25s (hot)
- Starting Method Direct On Line
- Terminal box¹ Left position
- Slip 1.00 %
- No load current 90.0 A
- Rotation¹ Both (CW and CCW)
- Output rating 200 HP
- Output 200 HP (150 kW)
- Insulation Class F
- Duty Cycle Cont.(S1)
- Synchronous speed 900 rpm
- Rated speed 891 rpm
- Locked rotor torque 190 %
- Degree of Protection IP56
- Number of poles 8
- Rated voltage 460 V
- Breakdown torque 210 %
- Ambient temperature -20°C to +40°C
- Voltage 460 V
- Number of Poles 8
- Service factor 1.15
- Approx. weight³ 3460 lb
- LRC 6.1x(Code G)
- Temperature rise 80 K
- Altitude 1000 m.a.s.l.
- Frequency 60 Hz
- Design B
- Mounting F-1
- Standard NEMA MG-1
- Frame L447/9T
- Moment of inertia (J) 255 sq.ft.lb
- Enclosure IC411 - TEFC
- Flange Without
- Rated current 242 A
- Rated torque 1180 ft.lb
- Noise level² 64.0 dB(A)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
