10263594 WEG AC Motors

Product Details

• Number of Poles
  2
• Locked rotor time
  36s (cold) 20s (hot)
• Rated torque
  14.9 ft.lb
• Rotation¹
  Both (CW and CCW)
• Frequency
  60 Hz
• Moment of inertia (J)
  0.7541 sq.ft.lb
• Temperature rise
  80 K
• Voltage
  208-230/460 V
• Flange
  Without
• Rated speed
  3530 rpm
• Locked rotor torque
  280 %
• Enclosure
  IC418 - TEAO
• Output rating
  10 HP
• Rated voltage
  208-230/460 V
• Service factor
  1.25
• Synchronous speed
  3600 rpm
• Material (FERT)
  50006910
• Insulation Class
  F
• Degree of Protection
  IP55
• L. R. Amperes
  227-208/104 A
Ambient temperature
-20°C to +40°C
Standard
NEMA MG-1
Frame
215Y
Design
B
Mounting
F-1
Slip
1.94 %
No load current
6.90-8.00/4.00 A
Altitude
1000 m.a.s.l.
Noise level²
72.0 dB(A)
Output
10 HP (7.5 kW)
Breakdown torque
350 %
Duty Cycle
Cont.(S1)
Number of poles
2
Terminal box¹
Left position
Rated current
25.5-23.4/11.7 A
LRC
8.9x(Code K)
Starting Method
Direct On Line
Approx. weight³
175 lb
