04089EP3HCT326V-W22 WEG AC Motors

Product Details

• Number of Poles
  45508 Pole
• Voltage
  575 V
• Output Rating
  14885 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• Frame
  324/6T
• Insulation Class
  F
• Noise level²
  69.0 dB(A)
• Frequency
  60 Hz
• Moment of inertia (J)
  9.16 sq.ft.lb
• Service factor
  1.15
• Rated voltage
  575 V
• Locked rotor torque
  270 %
• Synchronous speed
  900/1800 rpm
• Enclosure
  IC411 - TEFC
• Rated current
  38.3 A
• No load current
  14.4 A
• LRC
  7.0x(Code H)
• Ambient temperature
  -20°C to +40°C
• Locked rotor time
  16s (cold) 9s (hot)
Mounting
F-2
Number of poles
8/4
Terminal box¹
Right position
Output
40 HP (30 kW)
Approx. weight³
2.2 lb
Duty Cycle
Cont.(S1)
Rated speed
1780 rpm
Degree of Protection
IP55
Temperature rise
80 K
Output rating
10/40 HP
Number of Poles
8/4
Starting Method
Direct On Line
Standard
NEMA MG-1
Rated torque
118 ft.lb
L. R. Amperes
268 A
Flange
Without
Rotation¹
Both (CW and CCW)
Slip
1.11 %
Breakdown torque
280 %
Altitude
1000 m.a.s.l.
Voltage
575 V
