02009ST3QIE324TC-W22 WEG AC Motors

Product Details

• Number of Poles
  8 Pole
• Voltage
  460 V
• Output Rating
  20 HP
• Rated Speed
  880 rpm
• Flange Type
  C
• LRC
  5.0x(Code G)
• Degree of Protection
  IP56
• Approx. weight³
  530 lb
• Frequency
  60 Hz
• Slip
  2.22 %
• Locked rotor torque
  190 %
• Locked rotor time
  48s (cold) 27s (hot)
• Altitude
  1000 m.a.s.l.
• Ambient temperature
  -20°C to +40°C
• Terminal box¹
  Left position
• Number of poles
  8
• Rated voltage
  460 V
• Service factor
  1.25
• Enclosure
  IC411 - TEFC
• Flange
  C
Rated speed
880 rpm
Design
B
Synchronous speed
900 rpm
L. R. Amperes
142 A
No load current
16.0 A
Breakdown torque
220 %
Output rating
20 HP
Rated current
28.3 A
Moment of inertia (J)
9.37 sq.ft.lb
Mounting
F-1
Frame
324/6TC
Starting Method
Direct On Line
Noise level²
56.0 dB(A)
Number of Poles
8
Rated torque
119 ft.lb
Duty Cycle
Cont.(S1)
Rotation¹
Both (CW and CCW)
Standard
NEMA MG-1
Output
20 HP (15 kW)
Insulation Class
F
Temperature rise
80 K
Voltage
460 V
