01012OT3E256TC-S WEG AC Motors

Product Details

• Number of Poles
  6 Pole
• Voltage
  230/460 V
• Output Rating
  10 HP
• Rated Speed
  1180 rpm
• Flange Type
  C
• Output
  10 HP (7.5 kW)
• Breakdown torque
  229 %
• Approx. weight³
  230 lb
• LRC
  5.3x(Code G)
• Insulation Class
  F
• Noise level²
  59.0 dB(A)
• Rated current
  27.8/13.9 A
• Starting Method
  Direct On Line
• Standard
  NEMA MG-1
• Number of poles
  6
• Frequency
  60 Hz
• No load current
  14.7/7.33 A
• Mounting
  F-1
• Synchronous speed
  1200 rpm
• Rated speed
  1180 rpm
Moment of inertia (J)
2.50 sq.ft.lb
Ambient temperature
-20°C to +40°C
Output rating
10 HP
Slip
1.67 %
Design
B
Duty Cycle
Cont.(S1)
Voltage
230/460//190-220/380-415 V
Rated voltage
230/460 V
Rated torque
44.5 ft.lb
Enclosure
IC01 - ODP
Flange
C
L. R. Amperes
147/73.7 A
Locked rotor time
61s (cold) 34s (hot)
Rotation¹
Both (CW and CCW)
Terminal box¹
Left position
Frame
254/6TC
Service factor
1.15
Altitude
1000 m.a.s.l.
Number of Poles
6
Locked rotor torque
210 %
Temperature rise
80 K
