00718ET3E213T-S WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  7.5 HP
• Rated Speed
  1770 rpm
• Flange Type
  Without
• Frame
  213/5T
• Design
  B
• Noise level²
  60.0 dB(A)
• Rated voltage
  230/460 V
• Moment of inertia (J)
  0.9380 sq.ft.lb
• Duty Cycle
  Cont.(S1)
• Output rating
  7.5 HP
• Frequency
  60 Hz
• Locked rotor time
  32s (cold) 18s (hot)
• Altitude
  1000 m.a.s.l.
• Voltage
  230/460//190-220/380-415 V
• Breakdown torque
  300 %
• Degree of Protection
  IP55
• Synchronous speed
  1800 rpm
• No load current
  8.81/4.41 A
Ambient temperature
-20°C to +40°C
Flange
Without
Rated speed
1770 rpm
LRC
7.3x(Code J)
Temperature rise
80 K
Mounting
F-1
Terminal box¹
Left position
Slip
1.67 %
Rated torque
22.3 ft.lb
Starting Method
Direct On Line
Standard
NEMA MG-1
Rated current
18.4/9.18 A
L. R. Amperes
134/67.0 A
Enclosure
IC411 - TEFC
Number of poles
4
Output
7.5 HP (5.5 kW)
Insulation Class
F
Approx. weight³
117 lb
Number of Poles
4
Locked rotor torque
260 %
Service factor
1.15
Rotation¹
Both (CW and CCW)
