00709ET3H256T-W22 WEG AC Motors

Product Details

• Number of Poles
  8 Pole
• Voltage
  575 V
• Output Rating
  7.5 HP
• Rated Speed
  880 rpm
• Flange Type
  Without
• Number of Poles
  8
• Design
  B
• Approx. weight³
  293 lb
• Slip
  2.22 %
• LRC
  5.3x(Code G)
• Frame
  254/6T
• No load current
  5.20 A
• Frequency
  60 Hz
• Breakdown torque
  250 %
• Degree of Protection
  IP55
• Rated speed
  880 rpm
• Rated torque
  44.8 ft.lb
• Moment of inertia (J)
  4.43 sq.ft.lb
• Altitude
  1000 m.a.s.l.
• Rotation¹
  Both (CW and CCW)
Voltage
575 V
Rated current
8.88 A
Duty Cycle
Cont.(S1)
Insulation Class
F
Mounting
F-1
L. R. Amperes
47.1 A
Locked rotor torque
200 %
Service factor
1.25
Temperature rise
80 K
Starting Method
Direct On Line
Noise level²
54.0 dB(A)
Output
7.5 HP (5.5 kW)
Locked rotor time
59s (cold) 33s (hot)
Enclosure
IC411 - TEFC
Flange
Without
Rated voltage
575 V
Ambient temperature
-20°C to +40°C
Number of poles
8
Terminal box¹
Left position
Standard
NEMA MG-1
Synchronous speed
900 rpm
Output rating
7.5 HP
