00158ET3E56C-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 1.5 HP
- Rated Speed 1750 rpm
- Flange Type C
- LRC 8.2x(Code K)
- Temperature rise 80 K
- Approx. weight³ 37.9 lb
- Rated voltage 230/460 V
- Insulation Class F
- Mounting F-1
- Terminal box¹ Left position
- L. R. Amperes 33.1/16.6 A
- Design B
- Degree of Protection IP55
- Standard NEMA MG-1
- Rated current 4.04/2.02 A
- Locked rotor time 37s (cold) 21s (hot)
- Enclosure IC411 - TEFC
- Synchronous speed 1800 rpm
- Frame 56HC
- Duty Cycle Cont.(S1)
- Rotation¹ Both (CW and CCW)
- Slip 2.78 %
- Locked rotor torque 270 %
- Altitude 1000 m.a.s.l.
- Flange C
- Number of Poles 4
- Breakdown torque 300 %
- Service factor 1.15 (1.00 @ 208V)
- Noise level² 52.0 dB(A)
- Frequency 60 Hz
- No load current 2.17/1.08 A
- Number of poles 4
- Output 1.5 HP (1.1 kW)
- Rated torque 4.50 ft.lb
- Starting Method Direct On Line
- Voltage 230/460//190-220/380-415 V
- Rated speed 1750 rpm
- Moment of inertia (J) 0.1101 sq.ft.lb
- Ambient temperature -20°C to +40°C
- Output rating 1.5 HP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
