.7518OT3E56C-S WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  208-230/460 V
• Output Rating
  0.75 HP
• Rated Speed
  1760 rpm
• Flange Type
  C
• Output
  0.75 HP (0.55 kW)
• Locked rotor torque
  250 %
• Temperature rise
  80 K
• Standard
  NEMA MG-1
• LRC
  7.3x(Code K)
• Breakdown torque
  300 %
• Noise level²
  52.0 dB(A)
• Terminal box¹
  Without Terminal Box
• Rated voltage
  208-230/460 V
• No load current
  1.38-1.60/0.800 A
• Altitude
  1000 m.a.s.l.
• Voltage
  208-230/460//190-220/380-415 V
• Frame
  56C
• Locked rotor time
  37s (cold) 21s (hot)
• Output rating
  0.75 HP
Frequency
60 Hz
Insulation Class
F
Approx. weight³
23.7 lb
Rated current
2.54-2.30/1.15 A
Duty Cycle
Cont.(S1)
Mounting
F-1
Number of Poles
4
Starting Method
Direct On Line
Enclosure
IC01 - ODP
Number of poles
4
L. R. Amperes
18.5-16.8/8.40 A
Moment of inertia (J)
0.0712 sq.ft.lb
Rotation¹
Both (CW and CCW)
Rated speed
1760 rpm
Rated torque
2.24 ft.lb
Service factor
1.25 (1.00 @ 208V)
Slip
2.22 %
Ambient temperature
-20°C to +40°C
Synchronous speed
1800 rpm
Flange
C
