.5036OT3E56CFL-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 208-230/460 V
- Output Rating 0.5 HP
- Rated Speed 3490 rpm
- Flange Type C
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Slip 3.06 %
- No load current 0.776-0.900/0.450 A
- Ambient temperature -20°C to +40°C
- Frequency 60 Hz
- Rated torque 0.752 ft.lb
- Enclosure IC01 - ODP
- Flange C
- Rated speed 3490 rpm
- Rotation¹ Both (CW and CCW)
- Number of Poles 2
- Moment of inertia (J) 0.0389 sq.ft.lb
- Service factor 1.25 (1.00 @ 208V)
- Output rating 0.5 HP
- Output 0.5 HP (0.37 kW)
- Breakdown torque 280 %
- Mounting F-1
- Synchronous speed 3600 rpm
- Frame 56C
- Duty Cycle Cont.(S1)
- Approx. weight³ 16.8 lb
- Rated current 1.79-1.62/0.811 A
- Locked rotor time 70s (cold) 39s (hot)
- Standard NEMA MG-1
- Terminal box¹ Without Terminal Box
- L. R. Amperes 11.1-10.1/5.03 A
- Temperature rise 80 K
- Noise level² 62.0 dB(A)
- Voltage 208-230/460//190-220/380-415 V
- Rated voltage 208-230/460 V
- LRC 6.2x(Code K)
- Locked rotor torque 229 %
- Starting Method Direct On Line
- Number of poles 2
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
