RMEFGN Schmersal Indicator Lights

Product Details

• Sealing type
  Membrane, Lip gaskets, Form seals
• Mounting flange
  Yes
• Diameter hole, with tolerance indication
  22.3 + 0.4 mm
• Versions
  LED - Indicator light - Front plate mounting
• Design
  Round, Flat dome
• Illuminable
  Yes
• Diameter of the dome
  25 mm
• Ambient temperature, minimum
  -25 °C
• Installation conditions (mechanical)
  arbitrarily
• Material of the front ring
  Aluminium
• Fully insulated
  Yes
• Mounting
  Mounting flange ELM
• Spacing
  40 x 50 mm
• Colour of the dome
  Green
• Material of the dome
  Glass
• Height of the dome
  0.5 mm
• Diameter hole
  22.3 mm
• Degree of protection
  IP65
• Standards
  EN 60947-5-1, IEC/EN 60947-1
• Integral System Diagnostics, general
  Yes
Diameter of the front ring
39.5 mm
Ambient temperature, maximum
+75 °C
Colour of the front ring
Silver
Tightening torque of the screw
0.6 Nm
Thickness of the front panel, maximum
6 mm
Gross weight
55 g
Diameter total
39.5 mm
Thickness, of the front panel, minimum
1 mm
