AZM 415-02/02ZPKE 24VAC/DC Schmersal Safety Switch Interlocks

Product Details

• Enclosure coating material
  painted
• Power to unlock
  Yes
• Standards
  EN 60947-5-1, BG-GS-ET-19
• Active principle
  electromechanical
• Number of guard doors
  1
• Rated impulse withstand voltage Uimp
  4 kV
• Switching principle
  Creep circuit element
• Electrical power consumption, maximum
  10 W
• Rated control voltage
  24 VAC/DC
• Utilisation category AC-15
  4 A
• Thermal test current
  6 A
• Utilisation category DC-13
  24 VDC
• Switching element
  Opener (NC)
• Latching force, minimum
  150 N
• Length of sensor
  71.5 mm
• positive break travel
  5 mm
• Cable section, maximum
  2 x 2.5 mm²
• Positive break force, minimum
  15 N
• Width of sensor
  130 mm
• Emergency exit
  Yes
Rated insulation voltage Ui
250 V
Material of the contacts, electrical
Silver
Actuating speed, maximum
0.2 m/s
Enclosure material
Aluminium
Latching force, maximum
400 N
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Ambient temperature, minimum
-25 °C
Mechanical life, minimum
1,000,000 Operations
Cable section, minimum
2 x 0.75 mm²
Degree of protection
IP67
Clamping force in accordance with ISO14119 Fzh
3,500 N
Number of actuating directions
1
Ambient temperature, maximum
+50 °C
Gross weight
1,037 g
Terminal Connector
Screw connection
Height of sensor
100 mm
