W6557A4900 ROSS Controls Electronic Components
Part#:W6557A4900
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
ISO 5599-2 Valve, Size 2, W65 Series, 5/3 Double, Pressure Controlled, Spool & Sleeve
Product Details
- Construction Spool and Sleeve
- Actuation Pneumatic
- Size 3
- Default Position Normally Open
- Pilot Supply Minimum equal to or greater than inlet pressure
- Weight (kg) 0.7
- Height 3.18 in (80.8 mm)
- Pilot Type External
- Media Temperature 40 to 175 F (4 to 80 C)
- Weight 1.5 lb (0.7 kg)
- Length (mm) 64.5
- Application Standard Temperature
- Fluid Media Filtered air
- Operating Pressure (bar) 1 to 10
- Width (mm) 171.5
- Ambient Temperature (Celsius) 4 to 80
- Return Detented
- Width 6.75 in (171.5 mm)
- Series W65
- Seal Material Buna-N
- Center Position Power
- Ambient Temperature 40 to 175 F (4 to 80 C)
- Valve Body Material Cast Aluminum
- Length 2.54 in (64.5 mm)
- Mounting Base Mounted
- Poppet/Spool Material Stainless Steel
- Height (mm) 80.8
- Valve Type Directional Control
- Operating Pressure 15 to 150 psig (1 to 10 bar)
- Function 5/3 Double Pilot
- Valve Standard ISO 5599-2
- Media Temperature (Celsius) 4 to 80
- Avg Cv 2.3
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of W6557A4900 on Applied Automation is $444.75. Order now.
