W6077B2407W ROSS Controls Electronic Components
Part#:W6077B2407W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
ISO 5599-1 Valve, Size 1, W60 Series, 5/3 Double Open Center, Solenoid Controlled, Spool & Sleeve, 24 VDC
Product Details
- Ambient Temperature (Celsius) 4 to 80
- Seal Material Buna-N
- Connection EN 175301-803 Form A
- Ambient Temperature 40 to 175 F (4 to 80 C)
- Pilot Supply Minimum Must be ≥ inlet pressure
- Actuation Electrical
- Width 6.7 in (170 mm)
- Valve Standard ISO 5599-1
- Media Temperature (Celsius) 4 to 80
- Return Detented
- Valve Type Directional Control
- Media Temperature 40 to 175 F (4 to 80 C)
- Length 1.7 in (42 mm)
- Height (mm) 112
- Series W60
- Fluid Media Filtered Air
- Application Standard Temperature
- Center Position Open
- Manual Override Non-locking
- Size 1
- Operating Pressure Vacuum to 150 psig (10 bar)
- Poppet/Spool Material Stainless Steel
- Function 5/3 Double Solenoid
- Width (mm) 170
- Avg. Cv 0.8
- Construction Spool and Sleeve
- Weight (kg) 0.9
- Duty Rating Continuous Duty
- Operating Pressure (bar) Vacuum to 10
- Pilot Type Internal/External
- Height 4.4 in (112 mm)
- Mounting Base Mount
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Length (mm) 42
- Default Position Normally Open
- Weight 1.8 lb (0.9 kg)
- Voltage 24 VDC
- Valve Body Material Bar Stock Aluminum
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
