LX26DB67501W ROSS Controls Electronic Components

Product Details

• Thread Type
  G
• Pilot Supply Minimum
  equal to or greater than inlet pressure
• Series
  LX
• Outlet Pipe Size
  1"
• Return
  Air
• Poppet/Spool Material
  Acetal & Stainless Steel
• Duty Rating
  Continuous Duty
• Operating Pressure (bar)
  vacuum to 10
• Power Consumption
  1.5 watts
• Valve Type
  Directional Control
• Valve Body Material
  Cast Aluminum
• Default Position
  Normally Open
• Width
  2.5 in (63.5 mm)
• Ambient Temperature
  40 to 120 F (4 to 50 C)
• Seal Material
  Buna-N
• Manual Override
  Non-locking
• Voltage
  24 VDC
• Ambient Temperature (Celsius)
  4 to 50
• Function
  2/2 Single Solenoid
• Avg Cv
  12.2
Application
Vacuum, Leak Tight
Media Temperature
40 to 175 F (4 to 80 C)
Mounting
Base Mount
Media Temperature (Celsius)
4 to 80
Weight
3.5 lb (1.6 kg)
Height
6.34 in (161.0 mm)
Construction
Poppet
Fluid Media
Filtered Air
Connection
EN 175301-803 Form C
Height (mm
161
Actuation
Electrical
Length (mm
104.7
Weight (kg)
1.6
Length
4.12 in (104.7 mm)
Pilot Type
External
Operating Pressure
Vacuum to 145 psig (vacuum to 10 bar)
Inlet Pipe Size
1"
Width (mm)
63.5
