LX19NB97501Z ROSS Controls Electronic Components
Part#:LX19NB97501Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
LX Series 2/2 Solenoid Valve, Normally Closed, Port (In) 2" NPT, Port (Out) 2"NPT, 110/120 VAC
Product Details
- Poppet/Spool Material Acetal & Stainless Steel
- Height (mm 272.9
- Return Air
- Fluid Media Filtered Air
- Outlet Pipe Size 2"
- Height 10.74 in (272.9 mm)
- Application Vacuum, Leak Tight
- Pilot Supply Minimum equal to or greater than inlet pressure
- Valve Body Material Cast Aluminum
- Weight 19.3 lb (8.8 kg)
- Pilot Type External
- Media Temperature 40 to 175 F (4 to 80 C)
- Function 2/2 Single Solenoid
- Voltage 110/120 VAC
- Connection EN 175301-803 Form A
- Media Temperature (Celsius) 4 to 80
- Thread Type NPT
- Width (mm) 127
- Mounting Base Mount
- Operating Pressure (bar) vacuum to 10
- Default Position Normally Closed
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Series LX
- Width 5.0 in (127.0 mm)
- Manual Override Locking
- Duty Rating Continuous Duty
- Seal Material Buna-N
- Avg Cv 62.7
- Construction Poppet
- Ambient Temperature (Celsius) 4 to 50
- Actuation Electrical
- Valve Type Directional Control
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Length 6.75 in (171.5 mm)
- Inlet Pipe Size 2"
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Length (mm 171.5
- Weight (kg) 8.8
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
