LF28DB87101W ROSS Controls Electronic Components
Part#:LF28DB87101W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
LF Series 2/2 Solenoid Valve, Normally Open, Port (In) G1-1/2", Port (Out) G1-1/2", 24 VDC
Product Details
- Valve Type Directional Control
- Thread Type G
- Seal Material Buna-N
- Avg Cv 36.1
- Application General
- Media Temperature 40 to 175 F (4 to 80 C)
- Default Position Normally Open
- Width 3.75 in (95.3 mm)
- Return Spring Assisted Air
- Fluid Media Filtered Air
- Length (mm 139.7
- Height (mm 230.8
- Voltage 24 VDC
- Operating Pressure (bar) vacuum to 10
- Inlet Pipe Size 1-1/2"
- Duty Rating Continuous Duty
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Length 5.50 in (139.7 mm)
- Height 9.09 in (230.8 mm)
- Connection EN 175301-803 Form A
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Series LF
- Outlet Pipe Size 1-1/2"
- Actuation Electrical
- Pilot Type Internal/External
- Poppet/Spool Material Acetal & Stainless Steel
- Width (mm) 95.3
- Mounting Base Mounted
- Ambient Temperature (Celsius) 4 to 50
- Pilot Supply Minimum equal to or greater than inlet pressure
- Weight 9.3 lb (4.2 kg)
- Construction Poppet
- Media Temperature (Celsius) 4 to 80
- Valve Body Material Cast Aluminum
- Weight (kg) 4.2
- Function 2/2 Single Solenoid
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Manual Override Non-locking
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LF28DB87101W on Applied Automation is $670.50. Order now.
