D1223B1SLB ROSS Controls Electronic Components

Product Details

• Exhaust Pipe Size
  1/8"
• Height (mm)
  32
• Series
  12
• Media Temperature
  40 to 175 F (4 to 80 C)
• Width
  4.6 in (118 mm)
• Function
  3/2
• Ambient Temperature (Celsius)
  4 to 80
• Weight (kg)
  0.14
• Default Position
  Normally Open
• Ambient Temperature
  40 to 175 F (4 to 80 C)
• Length
  1.46 in (37 mm)
• Application
  General
• Fluid Media
  Filtered air
• Weight
  0.31 lb (0.14 kg)
• Outlet Pipe Size
  1/8"
• Mounting
  Inline
• Operating Pressure (bar)
  0.3 to 10
• Thread Type
  G
• Valve Type
  Directional Control
• Operating Pressure
  5 to 150 psig (0.3 to 10 bar)
Width (mm)
118
Actuation
Manual Selector Switch
Construction
Spool & Sleeve
Valve Body Material
Cast Aluminum
Return
Detented
Media Temperature (Celsius)
4 to 80
Height
1.26 in (32 mm)
Inlet Pipe Size
1/8"
Avg Cv
0.6
Length (mm)
37
