CX34NB35501 ROSS Controls Electronic Components
Part#:CX34NB35501
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 3/2 Air Pilot Valve, Normally Closed, Port (In) 1/2" NPT, Port (Out) 3/8"NPT
Product Details
- Application Vacuum, Leak Tight
- Media Temperature (Celsius) 4 to 80
- Weight (kg) 0.6
- Width (mm) 100
- Construction Poppet
- Operating Pressure (bar) vacuum to 10
- Inlet Pipe Size 1/2"
- Mounting Base Mount
- Ambient Temperature (Celsius) 4 to 50
- Thread Type NPT
- Height 2.83 in (71.9 mm)
- Duty Rating Continuous Duty
- Valve Body Material Cast Aluminum
- Length 2.83 in (71.8 mm)
- Width 3.94 in (100.0 mm)
- Series CX
- Pilot Supply Minimum equal to or greater than inlet pressure
- Function 3/2 Single Pilot
- Exhaust Pipe Size 1/2"
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Manual Override Non-locking
- Actuation Pneumatic
- Media Temperature 40 to 175 F (4 to 80 C)
- Avg Cv 3.5
- Height (mm 71.9
- Default Position Normally Closed
- Pilot Type External
- Seal Material Buna-N
- Outlet Pipe Size 3/8"
- Return Air
- Fluid Media Filtered Air
- Length (mm 71.8
- Valve Type Directional Control
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Poppet/Spool Material Acetal & Stainless Steel
- Weight 1.4 lb (0.6 kg)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CX34NB35501 on Applied Automation is $231.75. Order now.
