CX28NB87501W ROSS Controls Electronic Components
Part#:CX28NB87501W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 2/2 Solenoid Valve, Normally Open, Port (In) 1-1/2" NPT, Port (Out) 1-1/2"NPT, 24 VDC
Product Details
- Application Vacuum, Leak Tight
- Function 2/2 Single Solenoid
- Weight 10.0 lb (4.6 kg)
- Series CX
- Media Temperature (Celsius) 4 to 80
- Manual Override Non-locking
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Default Position Normally Open
- Outlet Pipe Size 1-1/2"
- Mounting Base Mount
- Ambient Temperature (Celsius) 4 to 50
- Poppet/Spool Material Acetal & Stainless Steel
- Weight (kg) 4.6
- Height (mm 218.2
- Pilot Type External
- Duty Rating Continuous Duty
- Operating Pressure (bar) vacuum to 10
- Length (mm 127
- Voltage 24 VDC
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Seal Material Buna-N
- Return Air
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Thread Type NPT
- Avg Cv 44.9
- Width 5.17 in (131.2 mm)
- Construction Poppet
- Inlet Pipe Size 1-1/2"
- Connection EN 175301-803 Form A
- Fluid Media Filtered Air
- Valve Body Material Cast Aluminum
- Height 8.59 in (218.2 mm)
- Width (mm) 131.2
- Valve Type Directional Control
- Media Temperature 40 to 175 F (4 to 80 C)
- Pilot Supply Minimum equal to or greater than inlet pressure
- Actuation Electrical
- Length 5.0 in (127.0 mm)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
