CX18NB77501W ROSS Controls Electronic Components
Part#:CX18NB77501W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 2/2 Solenoid Valve, Normally Closed, Port (In) 1-1/2" NPT, Port (Out) 1-1/4"NPT, 24 VDC
Product Details
- Application Vacuum, Leak Tight
- Media Temperature 40 to 175 F (4 to 80 C)
- Seal Material Buna-N
- Length 5.0 in (127.0 mm)
- Pilot Type External
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Poppet/Spool Material Acetal & Stainless Steel
- Avg Cv 44.9
- Default Position Normally Closed
- Media Temperature (Celsius) 4 to 80
- Thread Type NPT
- Width 5.65 in (143.4 mm)
- Series CX
- Duty Rating Continuous Duty
- Actuation Electrical
- Weight 10.0 lb (4.6 kg)
- Voltage 24 VDC
- Valve Body Material Cast Aluminum
- Height 8.45 in (214.6 mm)
- Connection EN 175301-803 Form A
- Construction Poppet
- Function 2/2 Single Solenoid
- Width (mm) 143.4
- Mounting Base Mount
- Ambient Temperature (Celsius) 4 to 50
- Pilot Supply Minimum equal to or greater than inlet pressure
- Weight (kg) 4.6
- Power Consumption 5.8 watts nominal, 6.5 watts maximum
- Fluid Media Filtered Air
- Height (mm 214.6
- Valve Type Directional Control
- Manual Override Locking
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Length (mm 127
- Return Air
- Operating Pressure (bar) vacuum to 10
- Inlet Pipe Size 1-1/2"
- Outlet Pipe Size 1-1/4"
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
