CX18DB85501 ROSS Controls Electronic Components
Part#:CX18DB85501
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 2/2 Air Pilot Valve, Normally Closed, Port (In) G1-1/2", Port (Out) G1-1/2"
Product Details
- Series CX
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Valve Body Material Cast Aluminum
- Width 4.55 in (115.5 mm)
- Valve Type Directional Control
- Pilot Type External
- Poppet/Spool Material Acetal & Stainless Steel
- Width (mm) 115.5
- Mounting Base Mount
- Fluid Media Filtered Air
- Length 5.0 in (127.0 mm)
- Ambient Temperature (Celsius) 4 to 50
- Weight (kg) 4.6
- Outlet Pipe Size 1-1/2"
- Construction Poppet
- Media Temperature (Celsius) 4 to 80
- Avg Cv 44.9
- Return Air
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Length (mm 127
- Actuation Pneumatic
- Duty Rating Continuous Duty
- Inlet Pipe Size 1-1/2"
- Application Vacuum, Leak Tight
- Thread Type G
- Operating Pressure (bar) vacuum to 10
- Weight 10.0 lb (4.6 kg)
- Default Position Normally Closed
- Media Temperature 40 to 175 F (4 to 80 C)
- Seal Material Buna-N
- Height 7.65 in (194.3 mm)
- Function 2/2 Single Pilot
- Manual Override Locking
- Pilot Supply Minimum equal to or greater than inlet pressure
- Height (mm 194.3
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CX18DB85501 on Applied Automation is $664.75. Order now.
