CX16DB57501W ROSS Controls Electronic Components
Part#:CX16DB57501W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 2/2 Solenoid Valve, Normally Closed, Port (In) G1", Port (Out) G3/4", 24 VDC
Product Details
- Series CX
- Function 2/2 Single Solenoid
- Outlet Pipe Size 3/4"
- Voltage 24 VDC
- Operating Pressure (bar) vacuum to 10
- Inlet Pipe Size 1"
- Application Vacuum, Leak Tight
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Manual Override Non-locking
- Height (mm 142.9
- Pilot Type External
- Duty Rating Continuous Duty
- Actuation Electrical
- Length 3.45 in (87.6 mm)
- Mounting Base Mount
- Pilot Supply Minimum equal to or greater than inlet pressure
- Weight (kg) 1.6
- Width 4.17 in (105.8 mm)
- Default Position Normally Closed
- Ambient Temperature (Celsius) 4 to 50
- Seal Material Buna-N
- Length (mm 87.6
- Return Air
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Connection EN 175301-803 Form C
- Weight 3.5 lb (1.6 kg)
- Thread Type G
- Media Temperature 40 to 175 F (4 to 80 C)
- Power Consumption 1.5 watts
- Width (mm) 105.8
- Construction Poppet
- Media Temperature (Celsius) 4 to 80
- Poppet/Spool Material Acetal & Stainless Steel
- Height 5.63 in (142.9 mm)
- Valve Type Directional Control
- Fluid Media Filtered Air
- Valve Body Material Cast Aluminum
- Avg Cv 12.3
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
