CX14DB45501 ROSS Controls Electronic Components
Part#:CX14DB45501
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
CX Series 2/2 Air Pilot Valve, Normally Closed, Port (In) G1/2", Port (Out) G1/2"
Product Details
- Construction Poppet
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Length 2.83 in (71.8 mm)
- Default Position Normally Closed
- Fluid Media Filtered Air
- Seal Material Buna-N
- Mounting Base Mount
- Valve Body Material Cast Aluminum
- Weight 1.4 lb (0.6 kg)
- Series CX
- Ambient Temperature (Celsius) 4 to 50
- Poppet/Spool Material Acetal & Stainless Steel
- Height 2.85 in (72.4 mm)
- Pilot Type External
- Operating Pressure Vacuum to 145 psig (vacuum to 10 bar)
- Weight (kg) 0.6
- Thread Type G
- Media Temperature (Celsius) 4 to 80
- Inlet Pipe Size 1/2"
- Height (mm 72.4
- Return Air
- Media Temperature 40 to 175 F (4 to 80 C)
- Manual Override Non-locking
- Actuation Pneumatic
- Application Vacuum, Leak Tight
- Pilot Supply Minimum equal to or greater than inlet pressure
- Width 3.19 in (81.1 mm)
- Function 2/2 Single Pilot
- Duty Rating Continuous Duty
- Avg Cv 3.5
- Outlet Pipe Size 1/2"
- Valve Type Directional Control
- Operating Pressure (bar) vacuum to 10
- Length (mm 71.8
- Width (mm) 81.1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CX14DB45501 on Applied Automation is $196.25. Order now.
