2773B2003Z ROSS Controls Electronic Components

Product Details

• Series
  27
• Manual Override
  Non-locking
• Default Position
  Normally Closed
• Fluid Media
  Filtered Air
• Pilot Type
  Internal/External
• Thread Type
  NPT
• Duty Rating
  Continuous Duty
• Application
  General
• Connection
  Hardwired
• Operating Pressure
  15 to 150 psig (1 to 10 bar)
• Weight
  2.5 lb (1.2 kg)
• Mounting
  Inline
• Valve Body Material
  Cast Aluminum
• Construction
  Poppet
• Media Temperature
  40 to 175 F (4 to 80 C)
• Voltage
  110/120 VAC
• Height
  6.88 in (175 mm)
• Valve Type
  Directional Control
• Operating Pressure (bar)
  1 to 10
• Seal Material
  Buna-N
Ambient Temperature (Celsius)
4 to 50
Length
8.92 in (227 mm)
Cv (1-2)
2.5
Pilot Supply Minimum
equal to or greater than inlet pressure
Ambient Temperature
40 to 120 F (4 to 50 C)
Height (mm)
175
Media Temperature (Celsius)
4 to 80
Poppet/Spool Material
Acetal, Stainless Steel
Cv (1-4)
3.1
Return
Detented
Function
3/2 Double Direct Solenoid
Actuation
Electrical
Weight (kg)
1.2
Power Consumption
190 VA inrush, 40 VA holding on 50 or 60 Hz
Width
3.09 in (78 mm)
Width (mm)
78
Length (mm)
227
Inlet Pipe Size
1/4"
Exhaust Pipe Size
1/2"
Size
3/8"
Outlet Pipe Size
1/4"
