LD400400 Red Lion Industrial Automation Components

LD400400 on Applied Automation
Red Lion

Part#:LD400400

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion LD400400, part of the LD series, is a digital counter designed for versatile applications requiring precise counting. It supports a wide range of supply voltages, including DC options from 21.6Vdc to 250Vdc and AC options from 50Vac to 250Vac, accommodating various industrial power supplies. This unit is designed for surface mounting and boasts a degree of protection rated at IP65 NEMA 4X, ensuring durability in challenging environments. It features two high-speed digital inputs (20kHz max.; Sink/Source) for INPUTS A and B, and an additional digital input (Sink/Source) for RESET or USER INPUT, providing flexibility in control and operation.

Product Details

  • Product series / family name
    Process indicators
  • Supply voltage (DC)
    21.6-250Vdc (24Vdc / 48Vdc / 60Vdc / 72Vdc / 100Vdc / 110Vdc / 120Vdc / 127Vdc / 200Vdc / 220Vdc / 250Vdc)
  • Supply voltage (AC)
    50-250Vac (48Vac / 100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Order code / Manufacturer SKU
    LD400400
  • Primary brand
    Red Lion
  • Mounting mode
    Surface
  • Main function
    Counter (Digital)
  • Display
    1 row x 4-digits red characters (101mm / 4" high) LED display
  • Digital inputs
    2 x digital inputs (high-speed counters; 20kHz max.; Sink/Source) (INPUTS A / B) 1 x digital input (Sink/Source) (RESET / USER INPUT)
  • Compliant with standard(s)
    CE EN 61010-1 EN 61010-2-030 RoHS compliant
  • Sub-range name
    LD series
  • Functions
    Digital Counter
  • Degree of protection
    IP65 NEMA 4X
  • Benefits
    Available in 4 or 6 digits versions Single or dual counter with rate indicator Programmable scaling and decimal points Built-in batch counting capability Programmable user input Universally powered dual 5A Form C relay Aluminium NEMA 4x case construction

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LD400400 on Applied Automation is $959.00. Order now.

LD400400 Related Documents

Red Lion - LD - Product Manual.pdf

Manufacturer warranty

LD400400 Red Lion
