C48TS003 Red Lion Industrial Automation Components

C48TS003 on Applied Automation
Red Lion

Part#:C48TS003

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion C48TS003 is a single-preset digital timer within the C48 series, featuring 2 user inputs and designed to fit a 1/16 DIN (48x48mm) panel cutout. It displays time with 7.62mm red or 5.08mm green digits on a reflective LCD without backlight. This timer supports a wide range of supply voltages, accepting AC input from 85 to 250Vac, including common values such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac, as well as DC input of 11-14Vdc, specifically 12Vdc. Its compact dimensions are 1/16 DIN (W48mm x H48mm / 1.89" x 1.89"), and it offers a degree of protection rated at IP65 NEMA 4X. For connectivity, it includes 1 x digital input (Sink/Source) for user input 1, 1 x digital input (Sink/Source) for START/STOP functions, 1 x digital input (Sink/Source) for user input 3, alongside 1 x digital output (NPN) and 1 x digital output (contact type NO).

Product Details

  • Product series / family name
    Process timers
  • Design
    2 user inputs 1/16 DIN (48x48mm) 7.62mm red / 5.08mm green digits / reflective LCD (no backlight)
  • Functions
    Single-preset digital timer
  • Degree of protection
    IP65 NEMA 4X
  • Sub-range name
    C48 series
  • Digital outputs
    1 x digital output (NPN) 1 x digital output (contact type NO)
  • Compliant with standard(s)
    CE EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Main function
    Timer (Digital)
  • Primary brand
    Red Lion
  • Supply voltage (AC)
    85-250Vac (100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Digital inputs
    1 x digital input (Sink/Source) (USER INPUT 1) 1 x digital input (Sink/Source) (START/STOP) 1 x digital input (Sink/Source) (user input 3)
  • Dimensions
    1/16 DIN (W48mm x H48mm / 1.89" x 1.89")
  • Supply voltage (DC)
    11-14Vdc (12Vdc)
  • Order code / Manufacturer SKU
    C48TS003
  • Display
    2 rows x 6-digits reflective LCD display 7.62mm high red characters (top row) 5.08mm high green characters (bottom row)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of C48TS003 on Applied Automation is $271.00. Order now.
