517FX-A-SC Red Lion Industrial Automation Components

517FX-A-SC on Applied Automation
Red Lion

Part#:517FX-A-SC

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion 517FX-A-SC is an Ethernet switch designed for industrial process control with monitored Ethernet switch capabilities. It features IGMP Auto Configuration, VLAN, QoS, Trunking or Link aggregation, Port Mirroring, and N-View Remote Monitoring Technology. This model operates on a supply voltage of 10-30Vdc, including redundant power inputs of 12Vdc and 24Vdc. It is equipped with 16 RJ45 ports supporting 10/100BaseTX, and one fiber optic SC connector for multi-mode fiber with a 100BaseFX rated current and a 2km rated optical fiber length. The switch includes advanced management firmware, operates within an ambient air temperature range for storage of -40 to +85 degrees Celsius, and achieves a maximum throughput of 2.6Gbit/s. The Ethernet switch is housed in a metallic case, suitable for DIN rail mounting, and is part of the N-Tron 500-A series, with a manufacturer specification of 17 ports.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

517FX-A-SC Red Lion

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Fast Shipping & Delivery

We deliver nationwide and international

Secure Payment Processing

Your Safety, Our Priority.

Warranty

Manufacturer warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Red Lion

Red Lion Controls has been a reliable supplier to customers globally for over 40 years. Our highly regarded industrial automation and networking solutions provide vital information and controls to improve efficiency, seamlessly integrating with various devices and applications.
