85692 Murr Elektronik AC/DC Power Supplies

Name: 85692
Brand: Murr Elektronik
Price: 669.45 USD
Availability: BackOrder

Part#:85692

Alt. Part#:85002

Category:AC/DC Power Supplies

Product Lifecycle:Active

Product description

85692 Murrelektronik - Emparro Power Supply 3-PHASE, IN: 360 - 500VAC OUT: 24-28V/20ADC, Power Boost - for 5 seconds 50% additional power

Product Details

Weight
1360 g
Series
Transformators/Power Supplies
Connection
Push-In spring clamp terminals
Parallel usage/serial usage
max. 3 units
Mounting method
DIN-rail mountable TH35 (EN 60715)
Power factor
0.65 (3× 500 V AC)
Efficiency
94.8% (3× 400 V AC); 94.5% (3× 480 V AC)
Output current
15 A (70 °C); 20 A (60 °C); 24 A (45 °C)
Frequency
50...60 Hz
Spikes
max. 90 mV ss/pp
Input voltage
3× 324...572 V AC/450...745 V DC
Temperature range
-40...+70 °C, ...+70 °C derating (storage temperature -40...+85 °C)
Ripple
max. 20 mV eff/rms
Standards
IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47
Input current
1.3 A (3× 360 V AC); 1.0 A (3× 500 V AC)
Protection
IP20
LED display
LED (green): OK; LED (red): overload, overheating or short-circuit
Power Boost
Iout N × 150% (min. 5 s)
Product article number of manufacturer
85692
Dimensions H×W×D
143×65×167 mm

Inrush current after 1 ms

max. 13 A (3× 500 V AC)

Output voltage

24 V DC (SELV), ±1%; 24...28 V adjustable

Mains failure bridging time

min. 40 ms (3× 500 V AC)

Input fuse (internal)

3× 6.3 A (T)

Relative humidity

5...95%, no condensation

Unit protection

short-circuit and overload protected, permanently by 20% (to 45 °C)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 85692 on Applied Automation is $669.45. Order now.
