85434 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  795 g
• Series
  Transformators/Power Supplies
• Output voltage
  12 V DC (SELV), ±1%; 12...15 V adjustable
• Output current
  10 A
• Frequency
  50...60 Hz
• Temperature range
  -40...+60 °C, ...+70 °C derating (storage temperature -40...+80 °C)
• Spikes
  max. 200 mV ss/pp
• Connection
  Push-In spring clamp terminals
• Input voltage
  85...265 V AC/90...250 V DC
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Mains failure bridging time
  min. 30 ms (100 V AC); 10 A (12 V DC)
• Product article number of manufacturer
  85434
• Relative humidity
  5...95%, no condensation
• Power factor
  0.88 (230 V AC)
• Efficiency
  91.4% (110 V AC); 93.2% (230 V AC)
• Ripple
  max. 50 mV eff/rms
• Input fuse (internal)
  6.3 A (T)
• LED display
  LED (green): OK; LED (red): overload, overheating or short-circuit
• Inrush current after 1 ms
  max. 10 A (230 V AC)
• Dimensions H×W×D
  123×50×138 mm
Unit protection
short-circuit and overload protected
Standards
IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47
Parallel usage/serial usage
max. 5 units/max. 2 units
Protection
IP20
Power Boost
Iout N × 150% (min. 4 s)
Input current
1.2 A (100 V AC); 0.6 A (230 V AC)
