85009 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  1400 g
• Series
  Transformators/Power Supplies
• Standards
  IEC 61010-2-201, EN 61204-3, EN 55022 B, EN 61000-3-2
• Parallel usage/serial usage
  max. 5 units/no
• Temperature range
  -25...+70 °C (storage temperature -40...+85 °C)
• Output current
  5 A (+55 °C); 3.73 A (+70 °C)
• Frequency
  50...60 Hz
• Dimensions H×W×D
  132×93×114 mm
• Spikes
  max. 100 mV ss/pp
• Efficiency
  91.3% (3× 360 V AC); 90.5% (3× 520 V AC)
• Power Boost
  Iout N × 150% (min. 4 s)
• Primary fusing external
  max. 3× 20 A
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Input voltage
  3× 324...572 V AC/480...745 V DC
• Connection
  Screw terminals
• Unit protection
  short-circuit and overload protected
• Protection
  Varnished board
• LED display
  LED (green): OK; LED (red): overload
• Input current
  3× 0.8 A
• Mains failure bridging time
  min. 17 ms (400 V AC)
Inrush current after 1 ms
max. 9 A
Output voltage
48 V DC (SELV), ±1%; 48...56 V adjustable
Ripple
max. 50 mV eff/rms
Relative humidity
5...95%, no condensation
Alarm output
electronic relay max. 30 V DC/0.1 A, group alarm
Product article number of manufacturer
85009
