57382 Murr Elektronik I/O Systems
Part#:57382
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
57382 Murrelektronik - CUBE20S DIGITAL OUTPUT MODULE DO8, 8x24VDC 0,5A NPN
Product Details
- Weight 65 g
- Series Field Bus System
- Temperature range 0...+60 °C (storage temperature -25...+70 °C)
- Switching current per output max. 0.5 A (short-circuit and overload protected)
- Diagnostic via LED per module and channel
- Galvanic isolation 500 V DC between outputs and internal communication
- Module supply via system connection
- Actuator supply UA 24 V DC (EN 61131-2), max. 4 A
- Current consumption max. 70 mA
- Mounting method DIN-rail mountable (EN 60715)
- Product article number of manufacturer 57382
- Short-circuit and overload yes
- Communication status via LED
- Connection Spring clamp plug-in terminals: max. 1.5 mm² (AWG 16)
- Monitoring - under voltage yes
- Protection IP20
- Diagnostic via BUS per module
- Dimensions H×W×D 109×12.9×76.5 mm
- Lamp load 5 W
- Monitoring - no voltage no
- Output delay time 175 ns
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 57382 on Applied Automation is $121.85. Order now.
